Peak to valley and back again.

Santacruz Hightower 4

M L

FRAME Carbon C

SHOCK FOX Float X Performance, 230x57.5

FORK FOX 36 Float Performance, Grip, 160mm

BRAKES SRAM DB8 Stealth

CRANKSET SRAM GX Eagle 148 DUB 32t

SHIFTERS SRAM GX Eagle, 12spd

REAR DERAILLEUR SRAM GX Eagle, 12spd

CASSETTE SRAM XG1275 Eagle, 12spd, 10-50t

SEATPOST OneUp Dropper Post, 31.6

TYRES Maxxis

WEIGHT 15,21kg

Sizes Available

Show: cm | in

SIZE	S (Low/High)	M (Low/High)	L (Low/High)	XL (Low/High)	XXL (Low/High)
A-Reach	430/427mm	455/452mm	475/472mm	495/492mm	520/517mm
B-Stack	611/613mm	625/627mm	634/636mm	652/654mm	665/668mm
C-Head Tube Angle	64.8°/64.5°	64.8°/64.5°	64.8°/64.5°	64.8°/64.5°	64.8°/64.5°
D-Seat Tube Length	380mm	405mm	430mm	460mm	500mm
E-Front Center	752mm	783mm	807mm	836mm	867mm
F-BB Height	342/339mm	342/338mm	342/338mm	342/338mm	342/338mm
G-BB Drop	31/34mm	31/34mm	31/34mm	31/34mm	31/34mm
H-Wheelbase	1183mm	1218mm	1245mm	1276mm	1311mm
I-Chainstay Length	432mm	435mm	438mm	441mm	444mm
J-Head Tube Length	100mm	115mm	125mm	145mm	160mm
K-Top Tube Length	572mm	600mm	627mm	648mm	675mm
L-Seat Tube Angle	77°/76.7°	77°/76.7°	76.7°/76.4°	76.9°/76.6°	76.9°/76.7°
M-Standover	706/701mm	708/703mm	711/706mm	714/709mm	719/714mm
